Pioneer 520

SXS 520 M2M

Specification Details
ClassificationSide X Side
Engine518cc liquid cooled single cylinder four-stroke
CarburationElectronic fuel injection (PGM-FI), 36mm throttle body
IgnitionFull-transistorized type with electronic advance
StarterElectric
TransmissionFive-speed automatic transmission with AT/MT modes with paddle shifting and reverse. Two drive modes include 2WD and 4WD
DriveDirect front and rear driveshafts
Front SuspensionIndependent double-wishbone; 5.8 inches of travel
Rear SuspensionIndependent double-wishbone with preload adjustability; 5.9 inches of travel
Power SteeringNo
Front BrakesDual 200mm hydraulic discs
Rear Brake170mm hydraulic disc
Front tyres24 x 8-12
Rear tyres24 x 10-12
Fuel Capacity (l)15.5L incl. 4.2L reserve
Bore x Stroke (mm)96.0mm x 71.5mm
Dimensions - Length (mm)2667
Dimensions - Width (mm)1270
Dimensions - Height (mm)1808
Wheelbase (mm)1854
Seat Height (mm)703
Ground Clearance (mm)216
Towing Capacity (kg)454
Front Rack Capacity (kg)N/A
Rear Rack Capacity (kg)204 (Bed Capacity)

TRX520FM6

5fwd/1rev manual

Specification Details
ClassificationHeavy duty ATV
Engine518cc Liquid-cooled, wet-sump, longitudinally mounted OHV 4-stroke single cylinder
CarburationPGM-FI 36mm
IgnitionFull-transistorized with electronic advance
StarterElectric
TransmissionAuto clutch with manual shift
Drive4wd Direct drive-shafts with TraxLok® switchable 2wd/4wd and locking front differential
Front SuspensionIndependent double wishbone; 185mm travel
Rear SuspensionDual A-Arm (IRS); 215mm travel
Power SteeringYes
Front Brakes190mm dual hydraulic discs
Rear Brake170mm single hydraulic disc
Front tyres25 x 8-12
Rear tyres25 x 10-12
Fuel Capacity (l)14.7L, incl. 4.9L res.
Bore x Stroke (mm)96.0 x 71.5
Dimensions - Length (mm)2185
Dimensions - Width (mm)1204
Dimensions - Height (mm)1240
Wheelbase (mm)1293
Seat Height (mm)919
Ground Clearance (mm)251
Towing Capacity (kg)599
Front Rack Capacity (kg)99 pounds
Rear Rack Capacity (kg)187 pounds

TRX520FA6

5fwd/1rev automatic dual clutch transmission

Specification Details
ClassificationHeavy duty ATV
Engine518cc Liquid-cooled, wet-sump, longitudinally mounted OHV 4-stroke single cylinder
CarburationPGM-FI 36mm
IgnitionFull-transistorised with electronic advance
StarterElectric
TransmissionAutomatic Dual Clutch Transmission; 5 speed + reverse and high/low
Drive4wd Direct drive-shafts with TraxLok® switchable 2wd/4wd and locking front differential
Front SuspensionIndependent Double wishbone; 185mm travel
Rear SuspensionDual A-Arm (IRS); 215mm travel
Power SteeringYes
Front Brakes190mm dual hydraulic discs
Rear Brake170mm single hydraulic disc
Front tyres25 x 8-12
Rear tyres25 x 10-12
Fuel Capacity (l)14.7L, incl. 4.9L res.
Bore x Stroke (mm)96.0 x 71.5
Dimensions - Length (mm)2185
Dimensions - Width (mm)1204
Dimensions - Height (mm)1237
Wheelbase (mm)1293
Seat Height (mm)922
Ground Clearance (mm)248
Towing Capacity (kg)599
Front Rack Capacity (kg)99 pounds
Rear Rack Capacity (kg)187 pounds

TRX520FM2

5fwd/1rev Manual foot-shift

Specification Details
ClassificationHeavy duty ATV
Engine518cc liquid cooled, wet-sump, longitudinally mounted OHV four-stroke single-cylinder
CarburationPGM-FI 36mm
IgnitionFull-transistorised with electronic advance
StarterElectric
TransmissionAuto clutch with manual shift; 5 speed and reverse
Drive4wd Direct driveshafts with TraxLok™ switchable 2wd/4wd and locking front differential.
Front SuspensionIndependent double-wishbone; 185mm travel
Rear SuspensionSwingarm with single shock; 185mm travel
Power SteeringYes
Front Brakes190mm dual hydraulic discs
Rear Brake170mm sealed mechanical drum
Front tyres25 x 8-12
Rear tyres25 x 10-12
Fuel Capacity (l)14.7L, incl. 4.9L res.
Bore x Stroke (mm)96.0 x 71.5
Dimensions - Length (mm)2185
Dimensions - Width (mm)1204
Dimensions - Height (mm)1237
Wheelbase (mm)1270
Seat Height (mm)924
Ground Clearance (mm)248
Towing Capacity (kg)384
Front Rack Capacity (kg)99 pounds
Rear Rack Capacity (kg)187 pounds

TRX520FE2

5fwd/1rev manual ESP push-button

Specification Details
ClassificationHeavy duty ATV
Engine518cc liquid cooled, wet-sump, longitudinally mounted OHV single-cylinder four-stroke
CarburationPGM-FI 36mm
IgnitionFull-transistorised with electronic advance
StarterElectric
TransmissionAuto clutch with electric shift; 5 speed and reverse
Drive4wd direct drive-shafts with TraxLok® switchable 2wd/4wd and locking front differential
Front SuspensionIndependent double-wishbone; 185mm travel
Rear SuspensionSwingarm with single shock; 185mm travel
Power SteeringYes
Front Brakes190mm dual hydraulic discs
Rear Brake160mm sealed mechanical drum
Front tyres25 x 8-12
Rear tyres25 x 10-12
Fuel Capacity (l)14.7L, incl. 4.9L res.
Bore x Stroke (mm)96.0 x 71.5
Dimensions - Length (mm)2103
Dimensions - Width (mm)1204
Dimensions - Height (mm)1220
Wheelbase (mm)1270
Seat Height (mm)869
Ground Clearance (mm)190
Towing Capacity (kg)384
Front Rack Capacity (kg)99 pounds
Rear Rack Capacity (kg)187 pounds

TRX420FA6-20

5fwd/1rev automatic and electric shift (ESP)

Specification Details
ClassificationUtility work ATV
Engine420cc liquid cooled, wet-sump, longitudinally mounted OHV 4-stroke single cylinder
CarburationPGM-FI 34mm
IgnitionFull transistorised with electronic advance
StarterElectric/Recoil
TransmissionAutomatic ESP push-button; 5 speed and reverse
DriveAutomatic Dual Clutch Transmission (DCT) with auto-shifting or electric shift
Front SuspensionIndependent double-wishbone; 185mm travel
Rear SuspensionDual A-Arm (IRS); 215mm travel
Power SteeringYes
Front Brakes190mm dual hydraulic discs
Rear BrakeSingle hydraulic 170mm disc
Front tyres24 x 8-12
Rear tyres24 x 10-11
Fuel Capacity (l)14.9L, incl. 4.9L reserve.
Bore x Stroke (mm)86.5 x 71.5
Dimensions - Length (mm)2146
Dimensions - Width (mm)1204
Dimensions - Height (mm)1203
Wheelbase (mm)1295
Seat Height (mm)901
Ground Clearance (mm)246
Towing Capacity (kg)384
Front Rack Capacity (kg)33 pounds
Rear Rack Capacity (kg)66 pounds

TRX420FA2-20

5fwd/1rev automatic and electric shift (ESP)

Specification Details
ClassificationUtility work ATV
Engine420cc liquid cooled, wet-sump, longitudinally mounted OHV 4-stroke single cylinder
CarburationPGM-FI 34mm
IgnitionFull transistorised with electronic advance
StarterElectric/Recoil
TransmissionAutomatic ESP push-button; 5 speed and reverse
DriveFront and rear driveshafts with TraxLok™ and torque-sensing front differential.
Front SuspensionIndependent double-wishbone; 170mm travel
Rear SuspensionSwingarm with single shock; 170mm travel
Power SteeringNo
Front Brakes190mm dual hydraulic discs
Rear Brake160mm sealed mechanical drum
Front tyres24 x 8-12
Rear tyres24 x 10-11
Fuel Capacity (l)14.9L, incl. 4.9L reserve.
Bore x Stroke (mm)86.5 x 71.5
Dimensions - Length (mm)2103
Dimensions - Width (mm)1204
Dimensions - Height (mm)1174
Wheelbase (mm)1270
Seat Height (mm)855
Ground Clearance (mm)183
Towing Capacity (kg)384
Front Rack Capacity (kg)33 pounds
Rear Rack Capacity (kg)66 pounds

TRX420FE1-20

5fwd/1rev automatic and electric shift (ESP)

Specification Details
ClassificationUtility work ATV
Engine420cc liquid cooled, wet-sump, longitudinally mounted OHV 4-stroke single cylinder
CarburationPGM-FI 34mm
IgnitionFull transistorised with electronic advance
StarterElectric/Recoil
TransmissionAutomatic ESP push-button; 5 speed and reverse
DriveFront and rear driveshafts with TraxLok™ and torque-sensing front differential.
Front SuspensionIndependent double-wishbone; 170mm travel
Rear SuspensionSwingarm with single shock; 170mm travel
Power SteeringNo
Front Brakes190mm dual hydraulic discs
Rear Brake160mm sealed mechanical drum
Front tyres24 x 8-12
Rear tyres24 x 10-11
Fuel Capacity (l)14.9L, incl. 4.9L reserve.
Bore x Stroke (mm)86.5 x 71.5
Dimensions - Length (mm)2103
Dimensions - Width (mm)1204
Dimensions - Height (mm)1174
Wheelbase (mm)1270
Seat Height (mm)855
Ground Clearance (mm)183
Towing Capacity (kg)384
Front Rack Capacity (kg)33 pounds
Rear Rack Capacity (kg)66 pounds

TRX420 4x4

5fwd/1rev manual foot-shift

Specification Details
ClassificationUtility work ATV
Engine420cc liquid cooled, wet-sump, longitudinally mounted OHV 4-stroke single cylinder
CarburationPGM-FI 34mm
IgnitionFull transistorised with electronic advance
StarterElectric/Recoil
TransmissionAutomatic ESP push-button; 5 speed and reverse
DriveAutomatic Dual Clutch Transmission (DCT) with auto-shifting or electric shift
Front SuspensionIndependent double-wishbone; 185mm travel
Rear SuspensionDual A-Arm (IRS); 215mm travel
Power SteeringYes
Front Brakes190mm dual hydraulic discs
Rear BrakeSingle hydraulic 170mm disc
Front tyres24 x 8-12
Rear tyres24 x 10-11
Fuel Capacity (l)14.9L, incl. 4.9L reserve
Bore x Stroke (mm)86.5 x 71.5
Dimensions - Length (mm)2146
Dimensions - Width (mm)1204
Dimensions - Height (mm)1203
Wheelbase (mm)1295
Seat Height (mm)901
Ground Clearance (mm)246
Towing Capacity (kg)384
Front Rack Capacity (kg)33 pounds
Rear Rack Capacity (kg)66 pounds

TRX420FA2-20

5fwd/1rev automatic and electric shift (ESP)

Specification Details
ClassificationUtility work ATV
Engine420cc liquid cooled, wet-sump, longitudinally mounted OHV 4-stroke single cylinder
CarburationPGM-FI 34mm
IgnitionFull transistorized with electronic advance
StarterElectric/Recoil
TransmissionAutomatic ESP push-button; 5 speed and reverse
DriveFront and rear driveshafts with TraxLok™ and torque-sensing front differential.
Front SuspensionIndependent double-wishbone; 170mm travel
Rear SuspensionSwingarm with single shock; 170mm travel
Power SteeringYes
Front Brakes190mm dual hydraulic discs
Rear Brake160mm sealed mechanical drum
Front tyres24 x 8-12
Rear tyres24 x 10-11
Fuel Capacity (l)14.7L, incl. 4.9L reserve.
Bore x Stroke (mm)86.5 x 71.5
Dimensions - Length (mm)2103
Dimensions - Width (mm)1204
Dimensions - Height (mm)1176
Wheelbase (mm)1270
Seat Height (mm)855
Ground Clearance (mm)183
Towing Capacity (kg)384
Front Rack Capacity (kg)33 pounds
Rear Rack Capacity (kg)66 pounds
